<h5>JBL CSMA180 80W Commercial Mixer-Amplifier</h5>

JBL CSMA180 80W Commercial Mixer-Amplifier
JBL $811.15 $529.00529.00
The JBL® CSMA180 is a highly efficient 4-input mixer amplifier with a single 80W speaker output at either 8/4Ω or 70V. The CSMA180 utilized HARMAN's DriveCore™ technology to provide the needed output power at up to 80% more efficiency than conventional designs.
SKU CSMA180
Quantity:
CSMA180
JBL CSMA180 80W Commercial Mixer-Amplifier
JBL
Authorized Dealer:JBL CSMA180 80W Commercial Mixer-Amplifier Authorized Dealer:

The new CS Series commercial mixer amplifiers from JBL are the next generation in commercial sound. The CSMA180 allows you to connect up to 4 different sources like CD players, satellite receivers, and MP3 players. Those inputs are mixed down to a single 70V speaker output with 80W of power. The CSMA180 even has a microphone input with voice priority so you can set it up as paging system that will duck out the music for any pages that come through. The CSMA180's highly efficient DriveCore amplifier makes these units environmentally friendly as they draw less power and due to their reduced size and weight, are cheaper to ship.

The CSMA180 offers unmatched ease of use, with a clean, front panel featuring only volume controls for each channel, master volume adjustment, adjustable bass and treble controls and a power switch. All the volume controls are surrounded by an illuminated ring, making them easy to see and operate in darkened environments. The amplifier can drive 8 ohm and 4 ohm loads and can be used with 70V and 100V distributed audio systems without the need for a separate transformer. In addition to balanced mic/line inputs, unbalanced RCA inputs and speaker connections, all units include RJ45 connectors for use with JBL CSR-V in-wall volume controls. All models feature a universal power supply which enables the ability to accept AC voltages from 100 to 240 VAC, 50/60Hz.

JBL Commercial mixer/amps are manufactured under HARMAN’s GreenEdge™ environmental initiative, conforming to lead-free RoHS standards and utilizing recycled copper, aluminum and steel, an energy-saving powder coat finishing process and other environmentally-conscious manufacturing processes. Their highly efficient DriveCore design reduces power consumption and yields much more efficient operation – up to 80 percent more efficient than previous designs. All models carry a 3-year no-fault transferable warranty.

Features:

  • 4 inputs with 1 output of 80 watts of power
  • Ideal for commercial and industrial use
  • Fanless, space-saving 1U design
  • Sleek industrial look with illuminated rings, making them easy to see and operate
  • Euro-block type mic/line input connectors and output connectors
  • Independent Bass and Treble controls for each output channel
  • Supports 70V and 100V distributed audio systems without the need for a separate transformer
  • Remote volume control capability using JBL CSR-V module and standard Ethernet cable
  • Priority muting
  • Configurable output routing
  • Utilizes Crown’s DriveCoreTM technology providing excellent audio performance with high efficiency
  • Manufactured to lead-free ROHS standards, utilizing recycled metals, and using an energy-saving powder coat process
  • Includes rack mounting kit
  • Three-Year, No-Fault, Fully Transferable Warranty completely protects your investment
  • Energy Star® Certified

Output 80W @ 4/8 Ohms (1kHz Power, THD+N<0.5%
Frequency Response +/- 1dB (@1W into 4 or 8 Ohms)
Load Impedance Stable from 2 - 16 Ohms
Sensitivity 1.4Vrms
Signal to Noise Ratio Greater than 100 dB - 1kHz, A-weighted
Input Impedance Balanced 20K Ohms/Unbalanced 10K Ohms
Max Input +20dBu Typical
Included Accessories Rack mounting kit
Dimensions 1.7" x 8.6" x 11.9" (43.3 mm x 218.5 mm x 303.4 mm)
Shipping Weight 180: 9.9 lbs (4.5 kg); 1120: 10.1 lbs (4.6 kg)

FREE standard ground shipping on orders over $99 to the 48 contiguous states. See Terms and Conditions for full details and exemptions.

All products are covered by ProAudioSuperstore.com's 30-day Return Policy. See Terms and Conditions for full details and exemptions.

Warranty
New product. Includes limited three year manufacturer warranty.
